Pharmaceutical 120hp Two Stage Medium Pressure Air Compressor For Bottle Blowing

    Buy cheap Pharmaceutical 120hp Two Stage Medium Pressure Air Compressor For Bottle Blowing from wholesalers

    Buy cheap Pharmaceutical 120hp Two Stage Medium Pressure Air Compressor For Bottle Blowing from wholesalers
    • Buy cheap Pharmaceutical 120hp Two Stage Medium Pressure Air Compressor For Bottle Blowing from wholesalers
    • Buy cheap Pharmaceutical 120hp Two Stage Medium Pressure Air Compressor For Bottle Blowing from wholesalers

    Pharmaceutical 120hp Two Stage Medium Pressure Air Compressor For Bottle Blowing

    Ask Lasest Price
    Brand Name : GooDSeaA
    Model Number : SE110W-20
    Certification : ISO,CE
    Price : USD31000/PC-USD32500/PCS
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 50pcs/month
    Delivery Time : 35days -45days
    • Product Details
    • Company Profile

    Pharmaceutical 120hp Two Stage Medium Pressure Air Compressor For Bottle Blowing

    Air/Water Cooled Medium-Pressure Screw Air Compressor For Bottle Blowing (120hp, 20bar)


    GooDSeaA 2-stage Oil-injected rotary screw air compressors provide a reliable air supply of up to 20-30bar for high-pressure applications in the toughest working conditions, for example Bottle blowing (PET), Pharmaceutical industry, Food industry, Rubber tire manufacturing, Hydropower, Well drilling, Military, Biological and Chemical industry and many more applications.


    Technical Data

    High Pressure Screw Air Compressor

    Model

    SE90W-20

    Note

    Free air delivery (m3/min)

    9.2

    324.76cfm

    Max working pressure (bar)

    20

    2.0Mpa

    Power (kW)

    90

    120hp

    Voltage (V/P/Hz)

    380V/3P/50Hz

    Voltage can be customized

    Noise level dB(A)

    78


    Cooling method

    Water cooling

    air cooling is optional

    Drive method

    Coupling


    Motor protection

    IP55,F


    Suction air temperature (℃)

    ≦50


    Outlet temperature (℃)

    Ambient Tem. + 8~10℃


    Compressed air control method

    Automatic(0-100%)


    Control method

    PLC Intelligent

    English

    Oil content

    1~3ppm


    Connection (mm)

    DN 40


    Dimensions (L×W×H) mm

    2466*1900*1918


    Weight (Kg)

    2750

    Features & Benefits


    *high efficiency motor coupled to air end via non-lubricated, flexible coupling.

    Flange-mounted for positive alignment;

    *Heavy-duty inlet air filter

    Two-stage, Oil-injected

    Inside safety element

    *Intelligent Touch Screen Controller.

    Easy pressure adjustment

    Capacity modulation range 100 to 40%

    Differential pressure indicator

    *Air-fluid separation

    ASME psi rated tank

    ASME pressure relief valve

    Pleated air-fluid separator element for lower initial pressure drop

    *Dependable, high-performance two-stage air end for maximum power savings.

    *Cooling

    Air-cooled units use mounted and piped aftercooler with quiet fan

    Water-cooled units feature an air-in-shell, water-in-tube aftercooler desig



    More Models


    MODEL

    POWER

    AIR FLOW

    m3/min

    PRESSSURE

    bar

    OUTLET

    CONNECTION

    WEIGHT

    kg

    DIMENSION

    L*W*H mm

    kw

    hp

    SE90W-20

    SE90W-25

    90120

    9.2

    8.5

    20

    25

    DN 4027502466*1900*1918

    SE110W-20

    SE110W-25

    110150

    11.6

    9.7

    20

    25

    DN 4029002466*1900*1918

    SE132W-20

    SE132W-25

    SE132W-30

    132180

    13.0

    11.8

    10.5

    20

    25

    30

    DN 5032002466*1900*1918
    SE160W-2016022015.525DN 5038502850*1950*1950

    SE200W-20

    SE200W-25

    200270

    21.0

    18.8

    20

    25

    DN 6542002980*2100*1950

    SE250W-20

    SE250W-25

    250340

    25.0

    22.0

    20

    25

    DN 6545003250*2250*2050

    Note: the above listed are of our standard models. For different needs, the special design service is available. Welcome to pre-sales technical consultation at any time.
