Air Oil Free Rotary Screw Compressor for Well 100% Clean Air
Constant Speed & Variable Speed Drives (VSD)
11-250KW 15-400 HP
(Energy efficiency and durability, energy savings up to 15-30% on
full-load)
1. Characteristics of Air Oil Free Rotary Screw Compressor for Well 100% Clean Air
a. Reasonable structure, ideal balance
A star wheel symmetry structure is arranged on both sides of the
screw of the oil free compressor, to make the oil free compressor
not only without unbalanced inertia force, but also cancel the
axial force and radial force on the screw,as well as it will be in
ideal force balance.
b. High Efficiency
Oil-free air compressor theoretically has no clearance volume,high
single machine capacity, ideal isothermal compression. Due to its
thermal conductivity, when the water is injected into the
compressor chamber, the temperature will fall to 45℃, close to the
suction temperature.
c. Oil-free
Water instead of oil, to achieve the four functions: lubrication,
cooling, sealing, noise reduction, to provide high quality 100%
oil-free air with no pollution, the water discharged without
special treatment,which conforms to the environmental requirements.
d. Low noise, small shaking
The power balance system of the oil-free air compressor can
effectively control the vibration source and balance the operation,
the foundation has no special requirement, the star wheel adopts
special custom polymer material, the working cavity is sprayed with
lubricating water, and there is no transmission gear in the middle,
so the operation noise is very low.
2. Company Introduction
Goodseaa Aviation Technology (Shanghai) Co., Ltd is a wholly-owned
subsidiary of Shanghai Success Engine Compressor Co., Ltd, SUCCESS
ENGINE is a professional manufacturer of rotary screw air
compressor and purifying equipment in China starting in the year of
2004.
Our main products are oil-injected screw air compressor,
water-lubricated oil-free screw air compressor, middle pressure
screw air compressor, centrifugal air compressor, vacuum pump,
aeration blower and other auxiliary equipment.
The professional design, manufacture, production of SUCCESS ENGINE
compressors strictly follow the ISO9001 quality managing system
which ensures that every product of SUCCESS ENGINE has reached the
international standard.
SUCCESS ENGINE compressors have been exported to Russia,
Kazakhstan, Indonesia, Malaysia, Vietnam, Saudi Arabia and so on.
We can offer compressors customized for wide ranges of pressure and
volume at highly competitive prices.
3. Specifications
GoodSeaA 132kw Water Lubricted Oil Free Screw Air Compressor |
Model | ZW22A |
Free air delivery (M3/min) | 3.6 / 3.0 m³/min |
Max Working pressure (bar) | 7 / 10bar |
Power (kW) | 22kw (30hp) |
Cooling Method | Air Cooled |
Voltage (V/P/Hz) | 380V/3P/50Hz (can be customized) |
Motor Speed (rpm) | 2950 |
Protection Degree | TEFC, IP55 |
Motor Efficiency | 95% |
Drive Method | coupling |
Start Mode | Variable Frequency |
Control System | PLC |
Water Softening Equipment | Yes |
Discharge Temperature | 30～50℃ |
Compressed Air Control Method | Automatic(0-100%) |
Noise level dB(A) | 68 |
Connection (mm) | Rp 1 |
Dimensions (L×W×H) mm | 1520x1060x1450 |
Weight (Kg) | 840 |
4. The other Models
| Model | Power (kw) | Pressure (bar) | Air Flow (m3/min) | Noise Level dB(A) | Outlet Connection | Weight (kg) | Dimension (LxWxH)mm |
ZW11A-7
ZW11A-10 | 11 | 7
10 | 1.6
1.4 | 66 | Rp 3/4 | 460 | 1100x845x1260 |
ZW15A-7 ZW15A-10 | 15 | 7 10 | 2.5 2.0 | 67 | Rp 3/4 | 620 | 1260x900x1360 |
ZW18A-7
ZW18A-10 | 18 | 7
10 | 3.0
2.5 | 67 | Rp 3/4 | 750 | 1520x1060x1450 |
ZW22A-7
ZW22A-10 | 22 | 7
10 | 3.6
3.0 | 68 | Rp 1 | 840 | 1520x1060x1450 |
ZW37A-7
ZW37A-10 | 37 | 7
10 | 6.2
5.8 | 71 | Rp 1 1/2 | 1010 | 1760x1160x1550 |
ZW45W-7 ZW45W-10 | 45 | 7 10 | 8.2 6.8 | 73 | Rp 2 | 930 | 1900x1250x1340 |
ZW55W-7
ZW55W-10 | 55 | 7
10 | 10.0
9.0 | 74 | Rp 2 | 970 | 1900x1250x1340 |
ZW75W-7
ZW75W-10 | 75 | 7
10 | 13.0
10.0 | 75 | Rp 2 | 1020 | 1900x1250x1340 |
ZW90W-7
ZW90W-10 | 90 | 7
10 | 15.0
12.8 | 76 | Rp 2 | 2050 | 2200x1600x1700 |
ZW110W-7
ZW110W-10 | 110 | 7
10 | 20.0
17.0 | 78 | DN 80 | 2330 | 2200x1600x1700 |
ZW132W-7
ZW132W-10 | 132 | 7
10 | 23.0
19.0 | 80 | DN 80 | 2560 | 2200x1600x1700 |
ZW160W-7
ZW160W-10 | 160 | 7
10 | 26.0
22.6 | 82 | DN 80 | 3000 | 2500x1800x1700 |
ZW250W-7
ZW250W-10 | 250 | 7
10 | 40.0
36.0 | 85 | DN 100 | 45000 | 3000x2100x2000 |
5. FAQ
Q: Are you a factory or trading company?
A: We are the professional air compressor/vacuum pump/ blower
manufacturer.
Q: Where does your company and factory locate in? How can I visit
you?
A: Our company locates in No.666, Xinbo Road, Maogang Town,
Songjiang District, Shanghai City 201606, China. It takes about one
hour from Shanghai Pudong airport or Hongqiao Airport to our
company.
Q: What does your company do regarding quality control?
A: Quality always enjoys the top priority. GoodSeaA attaches great
importance to quality control from beginning to the end.
Q: What is your after-sale service?
A: The guarantee period is 12 months from the date of the machine
installation or 15 months from the day of machine delivery. We will
take full responsibilities for the charges caused by the defects
during the guarantee period(This warranty does not cover human
damage or misuse of product).
Q: Do you offer consumables and wearing parts, too?
A: We supply all the necessary spare parts and wearing parts for
all equipments and on time.
Q: Which countries have you exported your products to?
A: Our group has been exporting our products to over sixty
countries, like Canada, the United States, Russia, Portugal,
Poland, Hungary, Turkey, South Africa, India, Singapore, the united
Arab Emirates, Egypt, Indonesia, Pakistan, Vietnam, Brazil, Peru,
Chile, Argentina etc.
6. Our workshop
