10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor

    Buy cheap 10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor from wholesalers

    Buy cheap 10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor from wholesalers
    • Buy cheap 10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor from wholesalers
    • Buy cheap 10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor from wholesalers
    • Buy cheap 10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor from wholesalers
    • Buy cheap 10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor from wholesalers
    • Buy cheap 10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor from wholesalers
    • Buy cheap 10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor from wholesalers
    • Buy cheap 10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor from wholesalers

    10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor

    Ask Lasest Price
    Brand Name : Good SeaA
    Model Number : SEYC7A-10/D
    Certification : ISO,CE,ASME
    Price : USD1800/pc - USD2300/pc
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 100pcs/ Month
    Delivery Time : 15days - 30days
    • Product Details
    • Company Profile

    10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor

    7.5 KW 10HP Permanent Magnet VSD Screw Air Compressor


    GoodSeaA air compressor VSD series(inverter driven compressor) and YC series(permanent magnetic variable frequency compressor) are new-conception energy-saving product. By varying the speed of the drive motor in accordance to the change of the air capacity required,it regulates the actual power accordingly and thus saves the energy effectively.By adopting the electronic inverter system and the technology of supplying the exact air capacity required and precise pressure controlling,VSD air compressor not only directly reduces energy consumption by 30% but also brings many other benefits,such as stabilizing the network pressure,eliminating the peak current on starting,etc. VSD compressor serves as the best choice for the modern industrial and mining enterprises to save energy.

    10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor


    1. Specification

    55kw 10bar Permanent Magnet Varibale Frequency Screw Air Compressor

    Type

    Permanent Magnet VFD type

    NOTE

    Model

    SEYC55A-10/D


    Free air delivery (m3/min)

    0.3-1.0


    Max working pressure (bar)

    10

    145psi

    Power (kW)

    7.5

    75hp

    Noise level dB(A)

    68


    Cooling method

    Air cooling


    Oil content (ppm)

    1~3


    Driver Motor

    380V/3P/50Hz

    can be customized

    Protection degree

    IP55, F


    Driving mode

    Inverter

    variable frequency

    Control system

    Intelligent Touch Screen PLC


    Compressed air control method

    Automatic(0-100%)


    Discharge Temperature

    Ambient temp+8~10℃


    Connection

    Rp2


    Dimensions (L×W×H) mm

    1300*1860*1340


    Weight (Kg)

    630


    2. Advantages of VSD Air compressor


    1) Variable Flow Control
    Adopt inverter to drive the compressor can adjust the rotation speed of the motor in real time according to the actual air compression. In case of high air consumption, the pressure remains unchanged, but the speed compensates automatically to meet the supply needs. When the air consumption is low, pressure is maintained constant and speed is automatically reduced to supply


    2) Stable Pressure
    The variable speed air compressor adopts PID for precision speed adjustment. Changes in the air amount of the system will be automatically tracked. The compressor will supply air at a constant pressure, which is the preset desired pressure plus or minus 0.1bar, to reduce power consumption.


    3) No Current Impact during Starting
    The air compressor is started via invert. The maximum starting current is 1.2 times the rated current for power frequency start. Hence, our variable speed air compressor exerts little impact on the grid during starting. It enjoys reduced stress and consequently prolonged service life.


    4) High Economical Efficiency
    Throughout the operating life of the air compressor, energy costs account for most of all costs. However, by using VSD, energy consumption is reduced by 30%.Therefore, the energy cost saved by a variable speed air compressor for three years is roughly equivalent to purchase price of the unit.

    10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor

    10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor

    3. More Models

    (YC=permanent magnet VSD air compressor; VSD= standard VSD air compressor)

    4.Products Examples

    10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor

    5.Application

    10hp 7.5KW 10Bar Permanent Magnet Frequency Screw Air Compressor


    5.Why Choose Us?


    1. We supply good quality air compressor with reasonable price.

    2. We are leading producer and innovator for air compressor products in China,we can produce the design according to your requirement easily,and we accept OEM.

    3.We have an efficient, rigorous and experienced R & D team.

    4. We have more than 15 years sales and service experience of domestic and international market.


    6.FAQ

    1. Are you factory?
    Yes,our factory is located in Shanghai China since year 2004.


    2. What's the delivery time?
    Generally,15-30days.


    3. What’s the average life of your air compressor?

    12-15years


    4. How long is your compressor warranty?
    Usually,1 year /12 Months for whole compressor machine. It can be extended after negotiation.


    5. Are you accept OEM/ODM,mark with client’s logo?

    Yes, it’s available.


    6. Whats your payment terms?

    Usually, 1)30% TT in advance and balance before the shipment. 2)100% irrevocable L/C at sight. 3)Western Union. The other terms can be discussed.


    7. GoodSeaA Factory(Success engine's another brand)

    Shanghai Success Engine Compressor Co., Ltd is a professional manufacturer for screw air compressor since 2004. Now our business expanded to Centrifugal Compressor and Turbo Blower that are produced in the brand, GoodSeaA. Success Engine's factory is located in Shanghai, occupying 13,000 m2, which is equipped with CNC, honing, three coordinate measur-ing machine, etc. With 17 years of experience during deeply cultivating domestic market, we have shared air compressor with foreign customers from 60 countries.
